504
High pressure gamma ionization chamber
General Specifications
| MAXIMUM LENGTH (INCH/MM) |
17.38/441.5 |
| MAXIMUM DIAMETER (INCH/MM) |
7.0/177.8 |
| EFFECTIVE LENGTH (INCH/MM) |
13.75/349.3 |
| CATHODE MATERIAL (INTERNAL/EXTERNAL) |
Aluminum |
| FILL GAS |
Argon |
| FILL PRESSURE (TORR) |
19000 |
| EFFECTIVE VOLUME (CM³) |
5200.0 |
| OUTER CASING MATERIAL |
Stainless Steel |
| ANODE CONNECTOR |
MHV |
| CATHODE CONNECTOR |
MHV |
| GUARD CONNECTOR |
N/A |
Operating Characteristics
| RECOMMENDED OPERATING VOLTAGE (VOLTS) |
500 |
| OPERATING TEMPERATURE RANGE °C |
-50 to +100 |
| MAXIMUM OPERATING VOLTAGE (VOLTS) |
2000 |
| GAMMA SENSITIVITY (A/R/HR - Cs-137) |
1.2E-8 |
