20287
Cylindrical bf3 neutron detector
GENERAL SPECIFICATIONS
| GAS PRESSURE (TORR) at 21°C |
880 |
| CATHODE MATERIAL (INTERNAL/EXTERNAL) |
Stainless Steel |
| MAXIMUM LENGTH (INCH/MM) |
4.875/123.8 |
| EFFECTIVE LENGTH (INCH/MM) |
2.5/63.5 |
| MAXIMUM DIAMETER (INCH/MM) |
1.18/30.0 |
| EFFECTIVE DIAMETER (INCH/MM) |
1.05/26.67 |
| CONNECTOR |
Flying Lead |
| EFFECTIVE VOLUME (CM³) |
35.46 |
| OPERATING TEMPERATURE RANGE °C |
-50 to +100 |
ELECTRICAL SPECIFICATIONS
| RECOMMENDED OPERATING VOLTAGE (VOLTS) |
1750 |
| OPERATING VOLTAGE RANGE (VOLTS) |
1500 - 2000 |
| MAXIMUM PLATEAU SLOPE (%/100 VOLTS) |
2 |
| TUBE CAPACITANCE (PF) |
7 |
THERMAL NEUTRON SENSITIVITY
| SENSITIVITY (CPS/NV) |
3.45 |
