30754
Fission Counter
General Specifications
| MAXIMUM LENGTH (INCH/MM) |
2.24/56.9 |
| MAXIMUM DIAMETER (INCH/MM) |
0.28/7.1 |
| CATHODE MATERIAL (INTERNAL/EXTERNAL) |
Nickel |
| EFFECTIVE DIAMETER (INCH/MM) |
0.18/4.6 |
| CONNECTOR |
Flying Lead |
| SENSITIVE LENGTH (INCH/MM) |
0.75/19.1 |
| FILL GAS |
Argon, Nitrogen |
| FILL PRESSURE (TORR) |
760 |
Neutron Sensitive Material
| ENRICHMENT (%) |
>93 |
| MATERIAL |
U235 |
| TOTAL QUANTITY (MG) |
0.23 |
Operating Characteristics
| RECOMMENDED OPERATING VOLTAGE (VOLTS) |
500 |
| OPERATING VOLTAGE RANGE (VOLTS) |
200-800 |
| BACKGROUND (COUNTS) |
0.6 |
| PULSE RISE TIME (NANOSECONDS) |
200 |
| NEUTRON SENSITIVITY (COUNTS/1E4 NEUTRONS) |
1 |
