4019
Mica end window alpha- beta – gamma proportional counter
General Specifications
| MAXIMUM LENGTH (INCH/MM) |
2.13/54.10 |
| MAXIMUM DIAMETER (INCH/MM) |
0.59/14.99 |
| GAS FILLING |
Neon |
| EFFECTIVE LENGTH (INCH/MM) |
1.44/36.58 |
| CATHODE MATERIAL (INTERNAL/EXTERNAL) |
Stainless Steel |
| EFFECTIVE DIAMETER (INCH/MM) |
0.36/9.14 |
| CONNECTOR |
Pin |
| OPERATING TEMPERATURE RANGE °C |
-40 to +75 |
| GAS PRESSURE (TORR) at 21°C |
300 |
| PATH LENGTH (INCH/MM) |
1.5/38.10 |
Window Specifications
| MATERIAL |
Mica |
| AREAL DENSITY (MG/CM²) |
2.0 |
| DIAMETER (INCH/MM) |
0.36/9.14 |
Electrical Specifications
| RECOMMENDED OPERATING VOLTAGE (VOLTS) |
550/800 |
| OPERATING VOLTAGE RANGE (VOLTS) |
500 - 1000 |
| CAPACITANCE (PF) |
2 |
