45697
Mica side window proportional counter
General Specifications
| MAXIMUM LENGTH (INCH/MM) |
3.7/94.0 |
| MAXIMUM DIAMETER (INCH/MM) |
1.0/25.4 |
| GAS FILLING |
Xenon |
| EFFECTIVE LENGTH (INCH/MM) |
2.2/56.0 |
| CATHODE MATERIAL (INTERNAL/EXTERNAL) |
Stainless Steel |
| EFFECTIVE DIAMETER (INCH/MM) |
0.78/19.8 |
| CONNECTOR |
Pin |
| OPERATING TEMPERATURE RANGE °C |
-40 to +75 |
| GAS PRESSURE (TORR) at 21°C |
400 |
| PATH LENGTH (INCH/MM) |
0.78/19.8 |
Window Specifications
| MATERIAL |
Mica |
| AREAL DENSITY (MG/CM²) |
2.0 - 2.5 |
| DIMENSIONS (INCH/MM) |
0.28 x 0.71/7.0 x 18.0 |
Electrical Specifications
| RECOMMENDED OPERATING VOLTAGE (VOLTS) |
1600 |
| OPERATING VOLTAGE RANGE (VOLTS) |
1500 - 1800 |
| CAPACITANCE (PF) |
3 |
| TYPICAL RESOLUTION (FWHM FE55) |
18 |
