49728
1036 cm² beta-gamma proportional counter
General Specifications
| MAXIMUM LENGTH (INCH/MM) |
17.02/432.3 |
| GAS FILLING |
Xenon |
| EFFECTIVE LENGTH (INCH/MM) |
14.51/368.5 |
| CATHODE MATERIAL (INTERNAL/EXTERNAL) |
Aluminum |
| CONNECTOR |
MHV |
| OPERATING TEMPERATURE RANGE °C |
0 to +50 |
| MAXIMUM WIDTH (INCH/MM) |
11.73/298.0 |
| GAS PRESSURE (TORR) at 21°C |
800 |
| EFFECTIVE WIDTH (INCH/MM) |
11.08/281.3 |
| PATH LENGTH (INCH/MM) |
0.50/12.7 |
Window Specifications
| MATERIAL |
Titanium |
| THICKNESS (INCH/MM) |
0.00047/0.012 |
| AREAL DENSITY (MG/CM²) |
5.0 |
| EFFECTIVE AREA (CM²) |
1036 |
Electrical Specifications
| RECOMMENDED OPERATING VOLTAGE (VOLTS) |
1450 |
| OPERATING VOLTAGE RANGE (VOLTS) |
1350 - 1600 |
| GAMMA SENSITIVITY Cs-137 (CPS/mR/HR) |
3000 |
| CAPACITANCE (PF) |
6 |
| TYPICAL RESOLUTION (FWHM FE55) |
16 |
| MINIMUM COUNTING LIFE (COUNTS) |
1.0E12 |
| PLATEAU SLOPE (%/100 VOLTS) |
3 |
